Validation

Regarding computing capabilities, the following summarizes the electromagnetic simulation programs and platforms available in the Area:

• Electromagnetic simulation capabilities: Ansys EM Suite 2023 R1, Altair FEKO 2023, EMA3D, FASCRO, SEMBA-FDTD.
• CAD and meshing capabilities: Rhinoceros, CADFix, CATIAv5, GiD 14, Altair HyperWorks, SpaceClaim, Paraview.

Computing platforms: HPC cluster with 22 machines, each with two Xeon E5-2680 v3 computing units at 2.50 GHz with 24 cores and 128 GB. Two visualization machines, each with two Xeon E5-2660 v3 computing units at 2.60 GHz with 20 cores and 128 GB.

Figure 3. Prediction of the radar signature of large aerospace platforms.

Figure 4. Effect of a radome on a Ku-band horn
